2.4-2.5 GHz Antenna

2.4-2.5 GHz Antenna

A 2.4-2.5 GHz antenna is composed of enclosure, antenna, cable and connector. It is suitable for wireless communications. This wireless antenna can be applied for 2.4-2.5 GHZ ISM band, IEEE 802.11b/802.11g/802.11n applications, wireless LAN, WIFI systems, long-range directional applications, point to point systems, point to multi-point systems wireless bridges, backhaul applications and wireless video systems.

Advantages of 2.4-2.5 GHz antenna
1. Waterproof grade is IP67, which means our wireless antennas are highly resistant to water.
2. WIFI antennas are corrosion and fire resistant.

Parameters of 2.4-2.5 GHz antenna

No. Item Specifications
1. Frequency (MHz) 2400 MHz to 2500 MHz
2. V.S.W.R (in BW) ≤ 2.0 : 1
3. Gain (Zenit) 2 dBi
4. Polarization Vertical
5. Impedance 50 Ω
6. Cable
7. Connector TNC or others
8. Plastic Housing Black

Service and Package
1. We guarantee replacement if quality problems of our 2.4-2.5 GHz antennas are founded within one year. In addition, lifetime maintenance service is provided for antennas.
2. Each wireless antenna is packaged with plastic bag and carton.

Jinchang Electron is a professional wireless antenna manufacturer who has 28 years’ experience. Our products include various antennas, combo antennas and interface wires and connectors for antennas. 70% of our antennas are exported to abroad. We have cooperated with many famous enterprises, such as Nokia, Motorola, Audi, Volkswagen and Coca-Cola.
